Plot Source Localization as Multi-View Glass-Brain Projections

Creates deterministic sagittal, axial, and coronal maximum-intensity projections from source amplitudes with real three-dimensional coordinates. The bundled outline is schematic and is not an MRI, patient anatomy, or a validation of the inverse solution.

Usage

eegPlotGlassBrain(
  x,
  source_data = NULL,
  views = c("sagittal", "axial", "coronal"),
  threshold_pct = 90
)

Arguments

x: A PhysioExperiment object.
source_data: Optional explicit source data. Supply a data frame with finite x, y, z, and amplitude columns, or a structured list with positions and declared amplitude/matrix reduction fields. If NULL, uses coordinate-bearing metadata from a new eegSourceEstimate() or eegBeamformer() result.
views: Non-empty unique character vector drawn exactly from "sagittal", "axial", and "coronal". Request order is preserved.
threshold_pct: Finite percentile in [0, 100]. The threshold is the type-8 quantile of absolute amplitude over the complete source set; ties are retained.

Value

A patchwork object for normal projections. When fewer than three rows survive thresholding, returns the first requested view as an eegPlotSource() ggplot fallback without applying a second threshold. Immutable "glassbrain_data" attributes retain the resolved sources, panel data, display transform, and threshold settings.

Details

Projection axes are sagittal y-z with depth x, axial x-y with depth z, and coronal x-z with depth y. Free-orientation source estimates are reduced by root-sum-square over orientations at each time and RMS over time. This non-negative summary is not a signed instantaneous current. A fixed 80 by 80 display grid retains the greatest absolute amplitude in each projected bin, with exact ties resolved by the smallest source ID. The affine display transform comes from the complete unthresholded coordinate cloud and does not modify amplitudes. The bundled outline is schematic: the plot is not MRI registration, patient anatomy, or validation of localization accuracy. Bare amplitude vectors and two-dimensional coordinates are rejected.

Examples

if (FALSE) { # \dontrun{
pe <- make_eeg(n_time = 500, n_channels = 19, sr = 250)
fm <- eegForwardModel(pe, method = "spherical", n_sources = 50)
localized <- eegSourceEstimate(pe, fm, method = "mne")
eegPlotGlassBrain(localized)
} # }
